Durable state

A state cell is a named value a run reads and writes directly: (scope, key) -> value, a small JSON document. It survives replay and the run, and it’s the same cell from a shell step, a polyglot script, an SDK, or a graph’s state step.

Concepts covers what a cell is and when to use one. This page is how, including the operations that stay correct when two runs touch the same key at once.

Where cells fit

You want	Reach for
A value between steps of one run	Run-scoped cell, or spool output set
Not re-running an expensive command on replay	spool step, whose result is a checkpoint
A value from this run’s last execution	Entity-scoped cell
“Has anyone handled this id?”	add on an entity cell
A shared counter or quota	incr on an entity cell
Only one run at a time in a region of the pipeline	a concurrency: lease

add answers “not more than once, ever”: the claim outlives the run, so a second run finds the key taken and skips. A lease answers “not at the same time”: it is held until the run ends, whatever the outcome, and the next run in line proceeds. The group can be per key: concurrency: "record-{{ input.record_id }}" on a step gives one lease per record, and a run waiting for one holds no agent. See run admission for a whole run’s concurrency:, and job-level concurrency: for one job’s.

Scopes

Every cell lives in one of two scopes:

Scope	How you address it	Lifetime
Run	the default - no flag	Dropped when the run is collected
Entity	--entity <name> (entity: on a graph step)	Outlives every run

Run scope is a durable scratchpad for one run. Entity scope is cross-run memory: two runs in the same project that pass the same entity name reach the same cell. You choose the name (crawler, ledger, counters), and it’s unique within the project.

Keys starting _spool/ are Hyperspool’s own. You can read them; writing one is refused, on the canvas as you type it and again when the step runs.

spool state set cursor 1200 --entity crawler   # write
spool state get cursor --entity crawler        # 1200
spool state list --entity crawler              # key<TAB>value<TAB>version per line
spool state delete cursor --entity crawler

On a graph the same verbs are op: get|set|delete on a state step. The SDKs have get, set, delete, list and add, spelled the way each language spells things: state_get(key, entity=...) in Python. incr and cas are on the CLI and graph steps only. Script commands lists every subcommand with its output and exit codes.

The poll cursor

The main use of entity scope. Run this on a schedule and each tick picks up where the last one left off:

since="$(spool state get last-seen --entity digest)"
latest="$(spool step poll -- sh -c 'echo $(( $1 + 10 ))' _ "${since:-0}")"
spool step notify -- echo "items ${since:-0} to $latest"
spool state set last-seen "$latest" --entity digest

Three consecutive runs print items 0 to 10, items 10 to 20 and items 20 to 30. The ${since:-0} covers the first tick: spool state get exits 0 and prints nothing for a cell nobody has written, so $since is an empty string rather than an error.

A step’s checkpoint can’t do this: checkpoints belong to one run, and this value has to cross from one run to the next.

When two runs want the same key

get then set has a gap in the middle. Two runs read the same absent cell, both see nothing, both decide they’re first, and the record gets processed twice. Three operations close that gap.

All three want entity scope. Only one run can reach a run-scoped cell, so a claim on it never loses and a swap has nobody to race: the step looks like a dedup while deduping nothing, and that only surfaces the day two runs arrive together. A state step with op: add or op: cas and no entity: is refused when you save the graph. In a script, spool state add and spool state cas without --entity are allowed, and act on a cell only this run can see.

add - claim a key

Writes the cell only if nothing holds it yet, and tells you whether you won. In a shell that’s the exit code: 0 you won, 3 someone else holds it, anything else means something broke.

order_id=1042
rc=0
spool state add "seen-$order_id" --entity ledger || rc=$?
case $rc in
  0) spool step process -- echo "processing order $order_id" ;;
  3) echo "order $order_id already handled" ;;
  *) exit 1 ;;   # unreachable agent, refused write - not an answer
esac

Branch three ways. A plain if spool state add … sends every failure down the else branch, so an agent that couldn’t reach the server reads as “someone else has it” and the record is silently skipped. Reserve the skip for exit 3.

Keep the || rc=$?. Scripts run under bash -eu, so a bare spool state add followed by case $? never reaches the case: losing the claim exits 3, errexit ends the run there, and the second run of a dedup ledger fails with no output at all.

That’s a dedup ledger, and it makes a workflow safe to trigger twice with the same payload. The value is optional (it defaults to true), since usually only the answer matters, though you can store something useful:

spool state add "seen-$order_id" "$(date -Iseconds)" --entity ledger

A ledger is for duplicates the run discovers about its own work. If what repeats is the submission, such as a webhook that delivers twice, the caller already knows, and spool submit --idempotency-key <k> is cheaper: the second delivery is answered with the first run, and no second run is created, admitted, or counted.

On a graph this is a state step with op: add, whose output is {"claimed": true|false}. Gate the work on it:

{
  "version": "hyperspool-graph/v1",
  "nodes": [
    { "id": "claim", "type": "state",
      "config": { "op": "add", "key": { "$template": "seen-{{ input.order_id }}" },
                  "value": true, "entity": "ledger" } },
    { "id": "process", "type": "shell",
      "if": "nodes.claim.output.claimed",
      "config": { "run": { "$template": "./process-order.sh {{ input.order_id }}" } } }
  ],
  "edges": [{ "from": "claim", "to": "process" }]
}

A duplicate trigger still starts a run. The run does nothing, and leaves a record that it happened.

incr - count without losing updates

{ "id": "bump", "type": "state",
  "config": { "op": "incr", "key": "processed", "by": 1, "entity": "counters" } }

From a script, same op:

n=$(spool state incr processed --entity counters --op tick)

The step’s output is {"value": <new total>, "version": <n>}, and the CLI prints the new value. by: defaults to 1 and may be negative, so a quota that hands out credits and returns them is two steps with by: -1 and by: 1.

Concurrent runs each land their own increment instead of overwriting one another. A cell holding something other than a number fails the step rather than resetting your count.

cas - a read-modify-write of your own shape

For updates that aren’t addition. get returns the cell’s version alongside its value; cas writes only if the version hasn’t moved:

{ "id": "read", "type": "state",
  "config": { "op": "get", "key": "config", "entity": "settings" } },
{ "id": "merge", "type": "code",
  "config": { "script": "…produce the new document…" } },
{ "id": "write", "type": "state",
  "config": { "op": "cas", "key": "config",
              "expected": { "$expr": "nodes.read.output.version" },
              "value": { "$expr": "nodes.merge.output.document" },
              "entity": "settings" } }

The get carries the same entity: as the cas; otherwise the version you read belongs to a different cell than the one you write.

From a script the exit code carries the answer:

v=$(spool state version config --entity settings)
doc=$(spool state get config --entity settings)
doc=$(python3 -c 'import json, sys; d = json.loads(sys.argv[1]); d["theme"] = "dark"; print(json.dumps(d))' "$doc")
rc=0
spool state cas config "$doc" --expect "$v" --entity settings --op merge || rc=$?
case $rc in
  0) echo "landed" ;;
  3) echo "someone else wrote first" ;;
  *) exit 1 ;;   # unreachable agent, refused write - not an answer
esac

The CLI prints nothing; exit 3 means someone wrote between your read and your write, so retry or fail the run. On a graph the step’s output is {"swapped": true|false}.

Read the version before the value. With version first, a write landing between the two calls leaves you an old version and a new value, so the swap fails and you retry. With value first, you hold a stale value and a version that already moved, so the swap succeeds and overwrites the other run’s write. That failure is silent and shows up only under contention.

Omitting expected: on a graph means “only if the cell is absent”, which is what add does. The CLI has no spelling for that; use spool state add.

State and replay

A state read or write is a plain operation. A polyglot script runs again from the top on every wake, so get, set and delete run again on each pass and get sees whatever the cell holds now, including other runs’ writes. Prefer last-write-wins or idempotent values, and don’t put a state call inside spool step: a step body can’t call spool.

add, cas and incr are recorded, on the CLI and on a graph. A replay pass reads back the first answer instead of racing again, so a run never loses a claim to its own earlier attempt, swaps twice or counts twice. A lost swap is recorded too, because the run acted on it.

incr and cas record their answer under --op <name>, which defaults to the key. A loop that swaps one cell several times needs a distinct name per attempt, and reusing a name in one run is refused.

A retry: re-runs the job on purpose, recorded answers and all, so a retried job’s incr counts again, and its cas re-attempts with a version its own first attempt already moved, reporting “someone else got there first” on a swap that in fact won. add survives a retry, because the cell records who claimed it. If a job carries retry: and counts, add a marker first or make the whole job idempotent.

Reading a cell from outside the run

The server holds the cells, so reading one needs neither a live run nor a free agent.

In the console, the run page has a State section listing the run’s cells and their current values. Hyperspool’s own _spool/ cells (a graph’s recorded step outputs, for instance) sit under a separate disclosure below yours.

From a terminal, name the scope, since out here you are not inside a run:

spool state get progress --run dev:default:run-jD3sGl   # that run's own cells
spool state list --run dev:default:run-jD3sGl           # all of them
spool state get last-seen --entity digest               # the project's store

A bare run-jD3sGl works too; it is qualified with your active project. The output matches what the same command prints inside a job, and an unset cell prints nothing and exits 0.

Over HTTP the same two scopes are GET …/runs/{id}/state[/{key}] and GET …/entities/{entity}/state[/{key}]. Fetching one key also returns its version, which a poller compares to notice a change without re-reading the value.

This is how a run publishes something for a reader outside it: the run writes the cell and the reader fetches it. A reader can only get answers the workflow prepared.

Before you rely on it:

• Reading a run’s own cells needs Viewer; entity scope needs Member. A run’s cells are its working data, like its logs. The entity store spans the project and outlives every run, so it sits at the level that could already read it by running a workflow that does.
• Cells are not masked. Secret masking applies to logs and not here, because a workflow reads a cell back as the real value. A cell holding a credential hands back that credential, so write accordingly.
• Nothing outside a run can write. A write from outside would race the workflow that owns the cell. To tell a running workflow something, send it a signal.

Run-scoped cells last as long as the run’s logs, so reading a swept run gives back nothing: an empty listing, or a 404 on a named key.

Cleaning up

Cells in run scope go when the run is collected. Entity cells stay until a run removes them, with this in a job or script:

spool state delete last-seen --entity digest

From a terminal the command is refused, since only a run writes cells. To clear one by hand, submit a one-line script that runs it.

Deleting a project removes every cell under it, both scopes.

Advanced

Appending to a list from several runs

A list that several runs append to at once needs a read, a change and a swap, retried when the swap loses. To keep it correct across a spool sleep, try add first, then fall back to cas with one --op name per attempt:

item="$(spool step pick -- sh -c 'echo "job-$$"')"

rc=0
spool state add items "[\"$item\"]" --entity inbox || rc=$?
attempt=0
while [ "$rc" = 3 ]; do
  attempt=$((attempt + 1))
  v="$(spool state version items --entity inbox)"
  list="$(spool state get items --entity inbox)"
  new="$(python3 -c 'import json, sys; print(json.dumps(json.loads(sys.argv[1]) + [sys.argv[2]]))' "$list" "$item")"
  rc=0
  spool state cas items "$new" --expect "$v" --entity inbox --op "append-$attempt" || rc=$?
done
[ "$rc" = 0 ] || exit 1

spool sleep 2s
echo "appended $item after $attempt swaps"

Six of those submitted together leave six items in the list. Both answers are recorded, so the pass after the sleep takes the same path and reads them back. Choosing between add and cas from a live get would take a different path on replay and fail the run.

An append is at least once: an agent that dies after the write and before its answer is recorded comes back, loses the swap it had in fact won, and appends again. The same gap applies to incr on an existing cell, where the next pass counts again. The window is small; if a count has to be exact across a crash, add a per-run marker first and increment only when the claim is yours. add itself is safe, because the cell remembers who claimed it.

Debouncing: act on the last of a burst

“Stamp a marker, sleep, then check whether I’m still the newest” doesn’t work in a script. The stamp is a set, so the replay pass after the sleep stamps it again and every arrival concludes it was last.

Draw a ticket instead. incr is recorded, so the number a run drew before the sleep is the number it still holds after:

key=order-7
value="$(spool step value -- date +%H:%M:%S.%N)"
mine=$(spool state incr "ticket:$key" --entity debounce --op ticket)
spool state set "latest:$key" "$value" --entity debounce

spool sleep 3s

# A live read, so it sees later arrivals' tickets.
if [ "$mine" = "$(spool state get "ticket:$key" --entity debounce)" ]; then
  echo "handling $(spool state get "latest:$key" --entity debounce)"
fi

Five arrivals half a second apart print one handling line, with the last one’s value. On a graph the same shape uses cas on the version the stamp returned, since a graph step runs once per run and needs no ticket.

The latest: cell is a plain set, so a waking loser stamps it again with its own older value on the way past. That is harmless when the winner wakes last, the normal case, and it is why the ticket decides who acts. If the value has to be the last arrival’s, carry it in the ticket cell itself with a cas.

On a graph, a get reads back your own write

A graph records a cell write, so a get of a cell this run has already written answers from that record without going to the store. That keeps a read the same across replay passes, but a graph can’t write a cell, wait, and then read it to see what another run did in the meantime: it sees its own value. Settle that with cas on the version the write returned, which does go to the store.

A polyglot script is the other way round: spool state get reads the store every time it runs, so it sees other runs’ writes. That is why anything derived from it has to be pinned by a recorded op (add, cas, incr) before the script branches on it.
